HY202A 制动器惯性试验台

1.  用途: 用于轻、轿车制动器和刹车片的摩擦磨损性能试验

2. 试验对象: 载重量3.5吨及以下汽车液压盘式 / 鼓式制动器总成或制动片。

3. 可执行标准:Standard: QC/T 564、QC/T479、QC/T239、QC/T237、JASO C406、SAE J212、SAE J2522、EceR90 、ISO 11157、AK Master、VW-TL110等。

4．测试项目包括：

      制动器制动性能测试（包括效能、热衰退、恢复、耐久、拖磨扭矩等）。

      驻车制动性能测试。

      水喷淋制动测试。

      静扭测试等；

5. 主要参数:

  主轴最高转速：2,100r/min

  最大扭矩：5000Nm

  惯量范围： 5.4-260 kg.m2

 HY202A brake inertial tester

1. Purpose: Friction and wear performance test for light, car brake and brake.

2. Test object: Vehicle hydraulic disc / drum brake assembly or brake sheet with a load of 3.5 tons or less.

3. Executable standards: Standard: QC/T 564, QC/T479, QC/T239, QC/T237, JASO C406, SAEJ212, SAEJ2522, ECER90, ISO 1157, AK Master, VW-TL110, etc..

4. Test projects include:

Brake brake performance test(including performance, thermal decay, recovery, durability, drag torque, etc.).

Test of parking braking performance.

Water spray brake test.

Static test, etc.;

5. Main parameters:

Maximum speed of spindle: 2,100r / min

Maximum torque: 5000 N M

Inertial range: 5.4-260 kg.m2
